M600C(8L)
Product model：M600C(8L)
Reference flow： 0-8000ml/min
一Technical specifications：
|
Speed Range |
0.1～600rpm |
Speed resolution |
0.1rpm |
|
Mode of adjustment |
Rotary encoder |
Display mode |
OLED color screen |
|
External control function |
Start and stop control, direction control, speed control | Communication function |
RS485(0-5v, 0-10V, 4-20mA, 0-10KHz control input)
|
|
Suitable for power supply |
220VAC±10﹪ 50HZ/60HZ |
Consume power |
≤200W |
| Working Environment | The temperature is 0 ~ 40 ° C and the relative humidity is < 80% |
Size (length × width × height)
|
310*205*185mm |
|
Drive weight |
11KG（No pump head） |
IPlevel |
IP31 |
二Main features
▲Servo motor subdivision drive, high precision, smooth running.
▲304 stainless steel casing, Black Mask, OLED display, unique, more extensive application fields.
▲OLED display current speed and running state, external control state, simple, intuitive, at a glance.
▲Rotary encoder speed and clockwise speed increase, and vice versa.
▲The three-position button switch controls the forward/reverse direction of operation and stops the middle position.
▲Full speed button, press to achieve rapid filling or emptying, up to restore the current speed.
▲With power-down memory function, power-down after re-power, in accordance with the state before power-down to work.
▲Can communicate with PC through RS-485, the company can provide free testing software and communication protocol.
▲When using the external control to control the speed, insert the external control module and pull the internal and external control switch to the external control position.
▲Can be used with optional accessories to achieve small batch filling, distribution;
Accessories are time distributor, Foot Switch, contact control module and so on, special requirements can consult the company.
三Pump head can be installed
▲Drive type：YZ25plus,YZ35mini,KZ25-6L,KZ35-8L
四Parameter flow
|
Drive type |
Pump Head |
Pump head material |
Apply Soft |
Reference flow range (mL/min) |
Number of channels |
|
M600c |
YZ25plus | PPS | 15# 24# 35# 36# | 0.34-6000 | 1 |
| YZ35mini | PPS | 73# 82# | 1.0-8500 | 1 | |
| KZ25-6L | AL | 15# 24# 35# 36# | 0.17-3000 | 1 | |
| KZ35-8L | AL | 73# 82# | 1.0-8500 | 1 |
五Typical applications
※Conventional fluid delivery ※Cooling circulation device ※Ink transfer
