- Flow rates: 0.7 to 8500 mL / min
- Dispensing volume: 0.1 mL to 99.9 L
- Speed: 10 to 600 rpm, CW/CCW
- Speed resolution: 1rpm
- Control mode: Control panel, external signal control and communication control are available
- Display: LCD for running state
- Dispensing volume: 0.1 ml to 99.9L
- Copy number: 0 to 9999, "0" means unlimited cycle
- Pause time : 0.1 s to 99.9 minutes, resolution is 0.1s.
- Back suction circle: 0 to 9.9 circle, resolution is 0.1 circle

- External control: star t/stop control, direction control, flow rates control (0 - 5V ,0 - 10V , 4 - 20 mA , 0 - 10KHz optional )

- Speed output: 166.7Hz - 10kHz corresponding to 10-600 rpm

- Start/stop output: OC gate signal
- Direction output: OC gate signal
- Communication interface: RS485
- Power supply: AC 110V±20%/140W or AC 220V±20%/140W optional
- Operating condition: Temperature 0 to 40°C, relative humidity < 80%
- Dimensions (L × W × H): 285 × 207 × 180 (mm)
- Drive weight: 6 kg

- IP rating: IP 31
